ITALSENSOR FOR RENEWABLE ENERGY!

ITALSENSOR SRL has devoted itself to developing innovative renewable energy solutions, in particular, to research and development of automation systems and high-efficient solar trackers for residential and industrial use.
Company offers innovative biaxial solar trackers equipped with high efficient photovoltaic monocrystalline panels (SunPower) with overall power of 1.4 kWp and 2.0 kWp.
sunpower_logo
The system ISOLAR moves the solar modules on dual axis, following the movement of the sun during the day, that allows to increment energy up to 50 % compared to a fixed structure of equal power. The system has an UPS module with integrated bypass, MPPT system and battery charge totally embedded and automatic with the possibility of management by local/remote (PC, tablet, smartphone). Storage system based on lead acid batteries bank/ AGM of high efficiency.

  • YOUR ENERGY INDEPENDENCE
  • ENERGY BILL SAVING
  • PROTECTION FROM FREQUENCY-VOLTAGE INSTABILITY AND BLACKOUT
  • REMOTE CONTROL
  • EASY D.I.Y. AND LOW MAINTENANCE COSTS
  • ECO FRIENDLY

tracker_small



IMAGES

Ralla_struttura
sensor_pos
inverter
batterie

Technical data

1400
(equiv. a 2 kWh fixed)
2000
(equiv. a 3 kWh fixed)
Installed power (Wp) 1380 2070
Max. solar wing surface 6 10
East-west rotational degree 0...270° with stop limit switches 0...270° con finecorsa di stop
South-North rotational degree 0...90° with adjustable stop limit switches 0...90° with adjustable stop limit switches
Controller sensor Light intensity, radiation Light intensity, radiation
East-West servo system (VDC) Gearbox 24 VDC Gearbox 24 VDC
Elevation servosystem (VDC) Gearbox 24 VDC Gearbox 24 VDC
Power consumption (Watt) 3 5
PV array dimensions W*H 3,2 m * 2,4 m 3,2 m * 3,3 m
Mechanical structure weight (kg) 490 530
Geographic position 25° ...90° latitude 25° ...90° latitude

Design

Development

Saving

Contact us, we would be glad to get in touch with you asap.
